Installation and Operation

Ensure the Suburban water heater is installed in a well-ventilated area, following the manual’s instructions. Secure the control housing to the RV’s wall framing. Connect water and gas lines properly, ensuring no leaks. Test the system after installation to confirm proper operation. Refer to the manual for specific models like SW6D or SW6DE for detailed guidance.

1.1 Pre-Installation Requirements

Before installing a Suburban water heater, ensure the location meets all safety and compatibility standards. The area must be well-ventilated, away from flammable materials, and provide adequate clearance as specified in the manual. Verify that the RV’s electrical and gas systems are compatible with the water heater’s requirements. Ensure the gas lines are properly sized and free from leaks. Check local building codes and regulations for compliance. The water heater must be installed in an upright position, and the venting system must be correctly configured to avoid obstructions. Failure to meet these requirements can result in unsafe operation or void the warranty. Always refer to the specific model’s manual for detailed pre-installation checks.

1.2 Step-by-Step Installation Process

Begin by unpacking the water heater and module board, ensuring all components are included and undamaged. Install chocks if required for stability, as shown in Figure 1A. Position the heater into the framed opening, securing the control housing to the RV’s wall with screws, ensuring they are recessed to clear the door flange. Connect water lines at the rear, referencing the appropriate figure for your model (e.g., SW6DM or SW6DEM). For electrical connections, place copper Ys in the heater as illustrated in Figure 10 for models with motor aid heat exchangers. Ensure proper venting and check for obstructions. Finally, test the system by running through ignition cycles to purge air from gas lines on the first startup.

Safety Precautions

If you smell gas, do not light any appliances or use phones nearby. Evacuate immediately, shut off the gas supply, and call your supplier or fire department. Ensure proper ventilation and avoid storing combustible materials near the heater.

2.1 General Safety Tips

Always follow the installation and operation manual guidelines for safe usage. Ensure the Suburban water heater is installed in a well-ventilated area, away from flammable materials. Never store gasoline or combustible liquids near the appliance. Keep the surrounding area clear of debris. Avoid touching electric switches or using phones if you smell gas. Properly maintain the unit to prevent leaks or malfunctions. Regularly inspect the venting system for blockages. Ensure all connections are secure and leak-free. Follow the manufacturer’s instructions for draining and storage during freezing temperatures. Always call a qualified technician for maintenance or repairs. Keep the manual and warranty information accessible for future reference. Adhere to all safety warnings and guidelines provided in the manual for optimal performance and safety.

2.2 What to Do in Case of Gas Leak

If you suspect a gas leak, do not attempt to light any appliance or use electrical switches. Immediately evacuate the area and avoid using phones nearby. Shut off the gas supply at the source or container. Open windows for ventilation but do not re-enter the vehicle. Contact your gas supplier or local fire department for assistance. Do not try to repair the leak yourself. Wait for a qualified technician to inspect and fix the issue. Follow all safety guidelines outlined in the manual to prevent accidents; Always prioritize safety and act quickly to minimize risks.

Maintenance and Troubleshooting

Regularly inspect the anode rod and replace it if corroded to prevent tank damage. Check for leaks in water and gas connections. Ensure proper ventilation to avoid carbon monoxide buildup. Clean the burner and flue annually to maintain efficiency. If issues arise, refer to the troubleshooting guide in the manual for common fixes or contact a certified technician for assistance.

3.1 Routine Maintenance Tasks

Regular maintenance is crucial for optimal performance and longevity of your Suburban water heater. Inspect the anode rod annually and replace it if severely corroded to prevent tank damage. Check the temperature-pressure relief valve by lifting the test lever to ensure it functions correctly. Flush the tank every 6-12 months to remove sediment buildup. Inspect all water and gas connections for leaks and tighten if necessary. Clean the burner ports and flue venting system to ensure proper airflow and combustion. Ensure the area around the heater is clear of flammable materials. Refer to the manual for specific instructions tailored to your model, such as SW6D or SW6DE. Always follow safety guidelines when performing maintenance tasks.

3.2 Troubleshooting Common Issues

Common issues with Suburban water heaters include the pilot light not igniting, no hot water, or leaks. If the pilot light fails to ignite, check for air in the gas lines or a faulty gas valve. For no hot water, ensure the thermostat is set correctly and reset if necessary. Leaks often occur at connections; tighten fittings and replace worn gaskets. If the ECO reset button trips, press it to restart the heater. Always refer to the manual for model-specific solutions, such as SW6D or SW6DE. If issues persist, contact Suburban support at 423-775-2131 or visit their website for detailed troubleshooting guides.

Technical Specifications

Suburban water heaters are direct vent gas models designed for RVs and mobile homes. Key features include direct spark ignition, efficient energy use, and durable construction. Models like SW6D and SW6DE offer reliable performance, easy installation, and low maintenance, ensuring consistent hot water supply in various conditions.

4.1 Key Features of Suburban Water Heaters

Suburban water heaters are designed for efficiency and reliability in recreational vehicles and mobile homes. They feature a direct vent gas system, ensuring safe and efficient operation. Direct spark ignition provides consistent and reliable lighting of the burner. The heaters are compact and lightweight, making them ideal for RV installations. They include an anode rod for corrosion protection, extending the tank’s lifespan. Energy-efficient designs minimize gas consumption while maintaining consistent water temperatures. The heaters are built with durable materials and are designed for easy installation and maintenance. Models like SW6D and SW6DE offer advanced features for optimal performance in various conditions.

Warranty and Support

Suburban water heaters come with a two-year limited warranty covering defects in materials and workmanship. For support, contact Suburban at 423-775-2131 or visit their office at 676 Broadway Street, Dayton, TN.

5.1 Warranty Terms and Conditions

The Suburban water heater is covered by a two-year limited warranty from the date of purchase. This warranty applies to the original purchaser and covers defects in materials and workmanship under normal use and maintenance. The warranty period begins on the purchase date, regardless of when the heater is installed or first used. Proper installation and maintenance, as outlined in the manual, are required to maintain warranty validity. Exclusions include damage from misuse, improper installation, or failure to follow safety guidelines. Consumers must provide proof of purchase to file a warranty claim. For detailed terms, refer to the warranty section in the manual or contact Suburban directly.

5.2 Contact Information for Support

For technical assistance, warranty inquiries, or general support, contact Suburban Manufacturing Company at 676 Broadway Street, Dayton, Tennessee 37321. The phone number is (423) 775-2131, and the fax number is (423) 775-7015. You can also visit their official website at www.Airxcel.com for more information. Suburban provides customer support for installation, maintenance, and troubleshooting. For warranty-related questions, refer to the warranty section in the manual or contact their support team directly. Ensure to have your product model number and serial number ready for efficient assistance. Suburban is committed to helping customers resolve issues promptly and effectively.

The Suburban water heater manual provides a comprehensive guide for installation, operation, and maintenance, ensuring optimal performance and safety. By following the outlined steps and adhering to safety precautions, users can enjoy reliable hot water in their RVs or mobile homes. Regular maintenance and prompt troubleshooting of issues are key to extending the product’s lifespan. Suburban offers a two-year limited warranty, providing peace of mind for customers. For any technical queries or support needs, reaching out to Suburban’s customer service ensures prompt resolution. This manual underscores the importance of proper usage and care, making it an essential resource for all Suburban water heater owners. Refer to the manual regularly to maintain your unit effectively and ensure years of trouble-free service.
